PRODUCT DETAILS
Structural Details
Component Material Parameters
Component |
Material |
Characteristics |
Frame |
Galvanized Steel Square Tube |
High-Strength Support |
Lower Frame |
3.0mm Reinforced C-shaped Steel Beam, 35cm Spacing |
Effective Sound Insulation, Reduces Vibration, Similar to Concrete Floor Structure |
Floor |
MGO Board/Cement Fiber Board |
High Strength, Fire Resistance, Water Resistance, Moisture Resistance |
Roof |
2.0mm Reinforced Weather-Resistant Steel Plate |
Bending Strength Equivalent to 3.6mm Ordinary Steel Plate, Load Capacity Over 2.5 Tons |
Side Wall Panel |
1.6mm~2.0mm Reinforced Weather-Resistant Steel Plate, Column 4.0mm~6.0mm, Sandblasted Surface |
Bending Strength Equivalent to 3.6mm Ordinary Steel Plate, Excellent Corrosion Resistance |
Insulation Material |
EPS, Rock Wool, Glass Wool, PU Sandwich Panel, Thickness 50/75/100mm, Applied in Walls and Roof |
Good Thermal Insulation and Cold Resistance |
Internal Partition |
Steel Plate Composite Insulation Material |
Sound Insulation, Thermal Insulation, Fire Resistance |
Corner Fittings |
High-Strength Steel Corner Fittings |
Used for Connection and Stacking |
Door |
Aluminum Casement Door / Sliding Door |
Equipped with Lock |
Window |
Aluminum Alloy or PVC Sliding Window |
Equipped with Safety Bars |
Traits ＆ Interior Configuration
Product Traits |
||
Feature |
Parameter |
|
Seismic Resistance |
Level 10 |
|
Wind Resistance |
Wind Speed Level 12 |
|
Thermal Insulation and Cold Resistance |
-40°C to 40°C |
|
Snow Load Capacity |
0.6kn/m² |
|
Live Load Capacity |
0.6kn/m² |
|
Wall Load Capacity |
0.6kn/m² |
|
Service Life |
More than 20 years |
|
Color |
Black, White or Customizable |
|
Interior Configuration |
||
Interior Configuration |
Details |
|
Shower Room |
Independent design, can include hot water equipment |
|
Toilet |
Flush toilet, washbasin, drainage system |
|
Electrical System |
Pre-wired with lighting and circuit distribution |
|
Furniture |
One-stop procurement according to customer needs |
|
Additional Facilities |
Air conditioning, ventilation equipment can be added |
|
